Tower Specifications

Applications: 4G/5G Small-Cell as well as Internet of Things (IoT) sites

Height Ranges: 20’ to 50’ typical but can be lower

Weight (Lbs.): 20’H: 150; 25’H: 180; 30’H: 210; 35’H: 240; 40’H: 270

Outer Diameter: 9.8” Standard OD (9.25” ID), ~12.4” with decorative wrap

Base Flange:

12“W x 12“D x 1.5“H
4x corner-mounts (3/4” or 1" bolts, 11.6" to 14.0" mounting circle)

Cable Access: 5"H x 2.5"W hand hole with secure cover 24" above grade

Colors: Gray, Black, Brown & Dark Green standard (custom available)

Construction: Patented composite structure with reinforced UV-resistant coating. Decorative foam-wrap features available with fluting, historic- designs, etc.

Equipment: Accommodates all Small Cell, Microwave and IoT equipment

Wind Speeds: Up to 180 mph (depending on loading)

Structural: Analysis per TIA-222, AASHTO and local building codes

Electrical: Bottom hand-hole available for routing power, fiber & data cables.
