9.8" OD Pole Specifications
Applications:
Lighting, IoT (Internet of Things), Wi-Fi, 4G/5G small cell sites
Height ranges:
Up to 40 feet above ground level (AGL)
Outer Diameter:
9.8" Standard OD (9.25" ID)
Colors:
Gray, black, brown & dark green standard (custom available)
Construction:
Patented composite structure with reinforced UV-resistant coating.
Equipment:
Accommodates all small cell, microwave and IoT equipment
Wind Speeds:
Up to 180 mph (depending on loading)
Structural:
Analysis per TIA-222, AASHTO and local building codes
Electrical:
Hand-hole and conduit-port available for routing power, fiber & data cables.
Base-flange Options:
12"W x 12"D x 1.5"H.
4x corner-mounts (3/4" or 1" bolts, 11.6" to 14.0" mounting circle)
